1600C Horizontal Flash Sintering Furnace with 3KW Programmable Power Source

Tube   Furnace

208 - 240 VAC, 50/60Hz,  5.2 KW max. power   consumption

Working temperature:  1600°C continuous and 1700°C   Max.

Heating Zone length: 18" ( 457 mm )

Constant temperature zone: 6"  ( 150 mm)   within +/- 1°C

  Temperature Control



PID automatic control via solid state relay with 30   steps programmable and  +/-1°C accuracy

Built-in Over Temperature and Thermocouple Failure   Protection

B-type thermal couple

  Vacuum Sealing Flanges
  & Sample Fixture




Vacuum Flanges are made of stainless steel   which can reach the vacuum to 10-2 torr by mechanical pump and 10-5    torr by turbo pump.
  Left Side Flange:

30 mm dia. Quartz observation window

 Needle valve with 1/4 NSP connector

Right Side   Flange：

KF25 vacuum port to connect to a vacuum pump

Two electric wires feedthrough. Wires are made of   Platinium with 1 mm diameter

Needle valve with mechanical vacuum gauge.

Sample fixture is built-in the inside flange.

This flange is slidable to make sample loading easy.

  Programmable AC Power Source




 The programmable AC power source is   to connect the electric wire at the feedthrough at the right side   flange.  After pre-heating,  AC power will pass a sample as   programa setting to produce more heat rapindly, which results in sample   sintered in high density.  The power parameters can be set via included   labtop. Power source specifications ae as the below

Input Voltage: AC220V±10%,  50/60Hz， single phase

Power Capacity:  3000 W Max.

Circuit Type: IGBT, PWM

Output Voltage： 50V-300V adjustable with ≤1% stability

Output Frequency:      50/60Hz fixed   with ≤0.01% stability

Protection:   Overload, over temperature , and   short circus

PC programmable：Laptop with pre-installed software is included for   program setting

Optional :       DC power    source 400V/10A is available upon request at the extra cost

Dimensions   & Weight

1950L×500 W ×720 H, mm

150Kg

Warranty

One year limited warranty with lifetime   support (Consumable parts such as tubes and o-rings are   not covered by the warranty)

Compliance

CE Certified
