Walk-in constant temperature and humidity room is used for humid heat test, high temperature test, low temperature test and high and low temperature gradient test of industrial products. It has the characteristics of wide range of limit temperature and humidity and high accuracy of actual temperature and humidity. Walk-in laboratory and studio can be used for temperature and humidity test of various components and whole machine.
Walk-in constant temperature and humidity room features:
1. The high strength and high reliability structure design ensures the high reliability of the equipment.
2. Large window design, convenient observation of laboratory test sample condition.
3. High wind speed, uniform sample exposure, effectively ensure the uniformity of the test room.
4. Unique door lock design, the use of lever principle, good sealing, with anti-lock function.
5. The library structure has high seismic resistance, good corrosion resistance, again installation, disintegration, convenient construction.
6. The inner box is made of SUS304 stainless steel plate, the outer box is made of plastic-sprayed galvanized color steel plate, and the middle is filled with temperature-resistant stress insulation material.
7. Heating system, refrigeration system, electrical system has been modular, and separate layout, better safety performance.
Walk-in constant temperature and humidity room product application field:
Walk-in constant temperature and humidity test room suitable for aerospace industry,PCB substrate, electronic chip IC, semiconductor ceramic and polymer material physical changes of the ideal test tool; Electronic and electrical components, metals, chemical materials, automation components, communication components, defense industry, physical changes of the ideal test tool. Can be used for batch or large parts, semi-finished products, finished products in high temperature, low temperature, wet and hot environment storage, transportation and use adaptability test
Technical parameters:
Custom size | 2, 4, 6, …. 40 m³ |
Inner box size (W*D*H) | 2250*1800*2000mm |
Temperature range | 0℃; -10℃; -20℃; -40℃~ +150℃ |
Humidity range | 20% ~ 95% RH, can be customized. When the temperature and humidity are combined, the humidity ranges from 65% to 95% |
Temperature fluctuation | ≤±1.0℃(no load) |
Humidity fluctuation | ±2.5%RH |
Cooling rate | Average 1 degree/min, linear cooling rate and rapid cooling rate can be customized |
Heating rate | Average 3 degrees/min, linear heating rate and rapid heating rate can be customized |
Temperature uniformity, deviation | Uniformity: ≤2℃; Deviation: ≤±2℃ |
Humidity uniformity and deviation | Uniformity: ≤ 3%RH; Deviation: ≤±5%RH |
