High and low temperature explosion-proof test box (single layer)High and low temperature explosion-proof test box (single layer)

High and low temperature explosion-proof test box (single layer)

    This product is designed for the standard test requirements of UL, EN, IEC, etc. To reach the low pressure storage state of the sample in a short time, it can automatically control the test cycle, monitor the pressure change in the box, and realize the automatic termination of the test

This product is designed for the standard test requirements of UL, EN, IEC, etc. To reach the low pressure storage state of the sample in a short time, it can automatically control the test cycle, monitor the pressure change in the box, and realize the automatic termination of the test. Analog battery and battery in pressure equal to or lower than 11.6kPa and ambient temperature (20 ± 5) storage for 6 hours, if the battery has no leakage, no exhaust, no disintegration, no rupture and no fire, and the battery or battery after the test is not less than 90% of the voltage before the simulation experiment, that is qualified.

Technical parameter:

Internal box   size

400x 400x   400mm (width x deep x high)

Contour size   of the unit

650x   650x1450mm (W x depth x H)

Internal box   material

SUS201   Stainless steel plate, 3.0mm thick

External box   material

1.5mm thick   cold-rolled steel sheet baking paint treatment

Observation window

250x250mm two   layers of tempered glass with stainless steel mesh

Pressure limit

0.5 ~ 100 KPa,   and the commonly used test pressure is 11.6 KPa

Vacuum display

Digital-explicit   vacuum table control

Box door

Single door   left open, the side of the door is equipped with an explosion-proof chain

Calculagraph

0-99H99, H/M /   S units can be switched

Pressure fluctuation

5%

Equipment   moving

There are four   universal direction casters at the bottom of the device, which can move   freely

Place content   plate

Two

Weight of   equipment

120Kg

Source

AC220V

Power

1K W
